ABB MicroFlex Analog Series Servo Drive

share
ABB MicroFlex Analog Series Servo Drive
Manufacturer: ABB

MicroFlex Analog is a compact servo drive, available in single phase from 110-230VAC or 3 phase 230VAC operation in current ratings of 3, 6 and 9A. MicroFlex Analog provides high performance servo control for both rotary and linear brushless motors. The motor feedback is software programmable, accepting encoder, SSI (Synchronous Serial Interface) or Halls only. Resolver feedback is available as a factory fit option. Motors can be tuned using the intuitivesoftware tools, MINT Workbench, which provides full auto-tuning capabilities and wizard based configuration. Extended capabilities include programmable notch filters to reduce or remove resonance in a machine. Step and direction inputs aloow MicroFlex to be used as a stepper axis replacement when upgrading to a servo package.

More+
Features Model
  • Brushless servo drive
  • Control of both rotary and linear servo motors
  • Direct online single-phase 115-230 VAC or 3 phase 230VAC
  • 3, 6 or 9 Amp continuous with 2x overload for 0.5 seconds.
  • Panel-mounting enclosure
  • Software selectable encoder, SSI (Synchronous Serial Interface) or Hall only feedback
  • Optional Resolver feedback
  • Simulated encoder output
  • Auto-tuning wizard and software oscilloscope facilities via MINT Workbench
  • Notch filters to eliminate mechanical resonance
  • Analog or pulse and direction command reference
  • LED status for error notification
  • RS232 serial channel for configuration (RS485 optional)
  • ActiveX libraries supplied free of charge
Mfr. Part No. Description
FMH2A03TR-EN23W 3A MicroFlex with RS232 programming interface
FMH2A06TR-EN23W 6A (12A peak) MicroFlex with RS232
FMH2A09TR-EN23W 9A (18A peak) MicroFlex with RS232
FMH2A03TR-EN43W 3A (6A peak) MicroFlex with RS485
FMH2A06TR-EN43W 6A (12A peak) MicroFlex with RS485
FMH2A09TR-EN43W 9A (18A peak) MicroFlex with RS485
