ABB MotiFlex e100 Series Servo Drive
Manufacturer: ABB

MotiFlex e100 is part of the e100 real-time Ethernet POWERLINK solution from ABB. System architecture is simplified by a single, highly configurable drive and motion control platform. The MotiFlex e100 can operate from a wide voltage range from 180 to 528 V AC three-phase, with DC bus energy sharing capability. The MotiFlex e100 servo drive is designed to control a wide range of motion applications from simple point-to-point motion to more complex applications. POWERLINK offers real-time control of many axes and Modbus TCP and Ethernet RAW offer a wide variety of control possibilities with PLCs, industrial PCs and other controllers. A universal digital encoder feedback accepts incremental encoder signals, SSI (Synchronous Serial Interface), EnDat v2.1/v2.2, 1V Sin/Cos encoders. Absolute multi-turn encoders are supported, with the position transmitted over the Ethernet back to the motion controller.

More+
Features Model
  • Ethernet POWERLINK for real-time control
  • Integrated hub for simple ‘daisy chain’ of Ethernet between drives and controller
  • TCP/IP Ethernet operation for less demanding applications
  • CANopen network manager for low cost I/O expansion directly from the drive
  • Rotary or linear brushless servo motors with 200% and 300% overloads for dynamic control
  • Closed loop AC vector motor control with 150% / 60s overload mode
  • V/Hz operation (open loop control)
  • 3 Phase 180-528 V AC (max) 50/60Hz
  • DC Bus energy sharing, with simple bus bar link system and integrated fuses as standard
  • Size A : 1.5, 3.0, 6.0, 10.5, and 16A rms
  • Size B : 21.5, and 26A
  • Size C : 34.5 and 65A
  • Flexible overloads :110% for 30s / 150% for 30s / 200% for 3s / 300% for 3s
  • Rated current can be increased with reduction in PWM frequency and overload selection
  • Universal encoder interface supporting: incremental encoder; synchronous serial interface (SSI); EnDat v2.1/v2.2, 1V Sin/Cos and BiSS encoders. Optional resolver interface and secondary encoder interface for dual loop control via option cards
  • 4 Digital inputs. Opto-isolated 24V. Two inputs can be programmed to capture axis position within 1 microsecond
  • 2 digital outputs. Opto-isolated 24V PNP. 50mA per channel
  • 1 x Analogue input +/-10V 12bit can be used for drive control via plug-in feedback card to provide simulated encoder output.
  • 2 x Expansion card slots for: secondary feedback, MINT programming options, fieldbus options and I/O expansion
  • Auto-tuning, configuration wizards and software oscilloscope facilities via MINT WorkBench for Windows simplify drive set-up
  • Notch and low pass filters to combat mechanical resonance issues
  • USB port for configuration
Mfr. Part No. Description
MFE460A001BW 1.5A 3 phase drive 180-528 VAC 50/60Hz Size A
MFE460A003BW 3.0A 3 phase drive 180-528 VAC 50/60Hz Size A
MFE460A006BW 6.0A 3 phase drive 180-528 VAC 50/60Hz Size A
MFE460A010BW 10.5A 3 phase drive 180-528 VAC 50/60Hz
MFE460A016BW 16.0A 3 phase drive 180-528 VAC 50/60Hz
MFE460A021BW 21.0A 3 phase drive 180-528 VAC 50/60Hz
MFE460A026BW 26.0A 3 phase drive 180-528 VAC 50/60Hz
MFE460A033BW 33.5A 3 phase drive 180-528 VAC 50/60Hz
MFE460A048BW 48.0A 3 phase drive 180-528 VAC 50/60Hz
MFE460A065BW 65.0A 3 phase drive 180-528 VAC 50/60Hz
