ABZ 090,929 Resilient seated butterfly valve
Manufacturer: ABZ

The ABZ Figures 090 and 929 valves can be used with all ANSI 125/150 pund flat or raised face type flanges. The seat face design eliminates the need for additional gaskets. Heavy wall pipe, lined pipe and flanges must meet minimum inside diameter requirements of dimension "E" to permit clearance of disc.

More+
Features Applications Model
  • Bodies are machined to high tolerances.Guaranteed standard dimensions for interchangeability of parts and operators.
  • Top bushings protects the stem from side thrust of operators.They are made of inmpact and corrosion resistant materials.
  • Special double V-shape of stem seal area for either vacuum or pressure use.
  • Two-piece body and one-piece disc/stem makes field replaced of seat and disc/stem quick and easy.
  • The special snap-in Resil-O-Seat design fixes seat in place without bonding. The Resil-O-Seat is 100% field replaceable - no special tools required.
  • Stem and body are isolated from line media by the interference fit of the primary seal created between the disc and seat.
  • Specially designed disc/stem prevents distortion of disc under high pressure. Thin disc allows for maximum open flow.
  • Disc edge is individually processed through machining for a mooth edge, providing a bubble tight shut-off and maximum seat life.
  • Resil-O-Seat forms a seal against all standard ANSI125/150 flanges. Gasketing requirements are eliminated.
  • Chemical and Food Industries
Mfr. Part No. Description
