ACME GroupD5 Three Phase Dry Type Distribution Transformer

Manufacturer: ACME

480 Delta Primary Volts - 208Y/120 Secondary Volts - Acme three phase low voltage distribution transformers are designed for industrial and commercial applications. All of Acme general purpose transformers are rated for 600 volts and below. Encapsulated units are offered in ratings up to 15kVA. Ventilated units are available in ratings up to 1000 kVA and meet the requirements of U.S. DOE 10 CFR Part 431 (NEMA TP1) efficiency standards.

More+

Features Model

With weather shield, UL Type 3R enclosure type 2 enclosure without weather shield
UL Class 220 deg C insulation system, 150 deg C rise
Extra large wiring compartment for easier installation and cooler case temperatures
NEMA standard bus bar terminals, no special tools needed to make clearly marked connections Tap changing easily accomplished with jumpers
Aluminum windings for increased insulation life, cooler operation, lower losses
Noise and vibration isolating pads standard to assure quiet operation
Large permanently legible nameplates on front
All units have ground studs for use with non-metallic conduit
Suitable for wall or "trapeze" mounting
80 deg C Rise
480 Delta Primary Volts; 208Y/120 Secondary Volts; May be used on a 4 wire 480Y/277 Volt Supply; 3 phase , 60Hz

Mfr. Part No.	Description
TP533128S	30 kVA 80 deg C Rise Dry Type Distribution Transformer
TP533138S	45 kVA 80 deg C Rise Dry Type Distribution Transformer
TP533148S	75 kVA 80 deg C Rise Dry Type Distribution Transformer
TP533158S	112.5 kVA 80 deg C Rise Dry Type Distribution Transformer
TP533168S	150 kVA 80 deg C Rise Dry Type Distribution Transformer
