ASCO 8320 Series Direct Acting Poppet Valve

Manufacturer: ASCO

Direct Acting Poppet Valves – 1/8″–1/4″

Direct acting valves available in normally closed, normally open, and universal constructions. Available either AC or DC operated with brass or stainless steel bodies. Covers broadest range of applications. All pipe connections in valve body to facilitate in-line piping.

More+

Features Model

All NPT connections are in the valve body to allow in-line piping
No Minimum Operating Pressure Differential required
Broadest range of applications
Mountable in any position

Mfr. Part No.	Description
8320G136	Standard Voltage;Max Operating Pressure (Air):125 PSI - 8.6 Bar
8320G172	Max Operating Pressure (Air):125 PSI - 8.6 Bar;Orifice Size:1/8 in
8320G015	Stainless steel construction;Pipe Size(NPT):1/4; Orifice Size (in):1/16;CV Flow Factor (Cv):0.06
8320G089	Max Op. Pressure(PSI):125 / 100 / 100; Pipe Size(NPT):3/8;Orifice Size:7/32;
8320G202	Max Op. Pressure(PSI):340 / 215 / 300; Pipe Size(NPT):3/8;Orifice Size:1/8;
8320G188	Max Op. Pressure(PSI):340 / 215 / 300; Pipe Size(NPT):1/4;Orifice Size:5/32;
