ELCO EV58A Topydic Series Shaft Incremental Encoder

share
ELCO EV58A Topydic Series Shaft Incremental Encoder
Manufacturer: ELCO

Topydic series encoders EV58A are widely used in industrial environments. It delivers outstanding performance in mechanical shock resistance and is capable of withstanding higher axial and radial loads. Its flexible and variant mechanical structure & electrical circuit designs ensure perfect matches with multiple types of flanges or servo motors. They are compatible with all control computers.

More+
Features Model Document
  • Max resolution is up 5000pulse/r, output frequency is up to 300khz
  • Stainless steel shaft Φ6/Φ8/Φ10, flexible coupling connection ensures encoder safety during operation
  • Various types of flanges, including imperial sizes
  • Metal housing for greater shock resistance; compact structure is suited for confined space mounting
  • Protection class IP65
  • Direct cable output or connector is more flexible and easy for maintenance
Mfr. Part No. Description
EV58A Φ31.75 clamping flange, shaft length 20mm
EV58B synchro flange, only fo shaft Φ6, shaft length 10mm
EV58C Φ36 clamping flange, shaft length 20mm
EV58D Φ63.5 suqare flange, shaft Φ31.75, shaft length 20mm
