A GE Field Control IC670MDL331 is a 120 VAC isolated output module. GE Field Control IC670MDL331 provides eight outputs arranged as four groups of 2. Each group on the GE Field Control IC670MDL331 is isolated from the others.
The power that runs the module itself comes from the power supply in the Bus Interface Unit.
An external source of AC power must be provided to power the loads.
LEDs
Individual LEDs (logic side), visible through the transparent portion of the module top, indicate the on/off status of each output. The abbreviations F1/PWR, F2/PWR, F3/PWR, and
F4/PWR refer to the Fuse OK LED for each of the four groups.
Mfr. Part No.
Description
IC670MDL331
Outputs per module, 8 (4 groups of 2 outputs each)
