Fanuc IC693PWR322 PLC
Manufacturer: Fanuc

GE Fanuc 90-30 IC693PWR322 is a 30 watt output power supply designed for 24 VDC or 48 VDC nominal inputs. GE Fanuc 90-30 IC693PWR322 will accept an input voltage range from 18 VDC to 56 VDC. GE Fanuc 90-30 IC693PWR322 provides 3 types of output: + 5 VDC output, + 24 VDC ”Relay”, and “Isolated” +24 VDC, which is used internally by some modules.

More+
Features Model
  • Determine total output load from typical specifications listed for individual modules in the
  • IC693 PLC Installation and Hardware Manual.
  • Multiply the total output load, determined in the previous step, by 1.5 to determine input power value.
  • Divide the input power by the operating source voltage to determine the input current requirement.
  • Since operating source voltage may vary, use the lowest measured or estimated input voltage to determine the maximum input current.
  • Allow for start-up surge current requirements.
  • Allow margin (10% to 20%) for variation.
Mfr. Part No. Description
IC693PWR322 Inrush Current 4 Amps peak, 100 milliseconds maximum
