Fanuc IC697MDL753 PLC
Manufacturer: Fanuc

The 5/48 Volt DC 0.5 Amp Negative Logic Output Module GE Fanuc 90-70 IC697MDL753 provides 32 output points in two isolated groups with 16 points in each group. GE Fanuc 90-70 IC697MDL753 is a wide range module in that the rated voltage can be 5 volts DC or 10 to 60 volts DC. GE Fanuc 90-70 IC697MDL753 provides a high degree of inrush current at 10 volts to 60 volts which makes the outputs suitable for a wide range of loads which have such characteristics.

More+
Features Model
  • 32 Points - Two isolated groups of 16 points each
  • 0.5 amp capacity per point
  • High inrush capacity (10x rated current)
Mfr. Part No. Description
IC697MDL753 Output Module, 5/48 Volt DC 0.5 Amp Negative Logic, 32 Points
