Hammond 1182 Toroid Power Transformer
Manufacturer: Hammond

Hammond Manufacturing 1182 Series Toroid Power Transformers have a low profile, are lightweight, cool running/high efficiency, and a low stray magnetic flux leakage (low EMI) due to its core shape. They feature dual 117/234VAC primary, 50/60Hz operation and 1,500VA size supplied with a potted center for extra strength.

The 1182 series is CSA certified to C22.2 #66 and is CE compliant to IEC 61558-2-4. This series replaces Hammond Manufacturing 182 Toroid Series.

More+
Features Model
  • Torodial transformer benefits:
  • low profile
  • lightweight
  • cool running/high efficiency
  • low stray magnetic flux leakage (low EMI) due to core shape
  • Dual 117/234 VAC primary, 50/60Hz operation
  • 1,500 VA size
  • Supplied with a potted center for extra strength
  • Supplied with two rubber insulating pads, one metal centering washer, and all mounting hardware (except the 1,500VA size)
  • Minimum 8" long flexible leads
  • Manufactured using Class B (130°C) materials
  • Hi-Pot test of 4,000VAC RMS between primary & secondary
  • UL recognized up to UL506 (XPTQ2 Guide)
  • CSA certified to C22.2 #66
  • CE compliant to IEC 61558-2-4
Mfr. Part No. Description
1182L6 Secondary Voltage (R.M.S.), VA, 30
1182N6 Secondary Voltage (R.M.S.), VA, 50
1182Q6 Secondary Voltage (R.M.S.), VA, 80
1182K9 Secondary Voltage (R.M.S.), VA, 30
1182M9 Secondary Voltage (R.M.S.), VA, 50
1182N9 Secondary Voltage (R.M.S.), VA, 80
1182Q9 Secondary Voltage (R.M.S.), VA, 120
1182K12 Secondary Voltage (R.M.S.), VA, 30
1182L12 Secondary Voltage (R.M.S.), VA, 50
1182M12 Secondary Voltage (R.M.S.), VA, 80
1182P12 Secondary Voltage (R.M.S.), VA, 120
1182Q12 Secondary Voltage (R.M.S.), VA, 160
1182S12 Secondary Voltage (R.M.S.), VA, 225
1182T12 Secondary Voltage (R.M.S.), VA, 300
1182W12 Secondary Voltage (R.M.S.), VA, 1000
1182J15 Secondary Voltage (R.M.S.), VA, 30
1182K15 Secondary Voltage (R.M.S.), VA, 50
1182M15 Secondary Voltage (R.M.S.), VA, 80
1182N15 Secondary Voltage (R.M.S.), VA, 120
1182P15 Secondary Voltage (R.M.S.), VA, 160
