Hammond 118944 Radiola Replacement Transformer
Manufacturer: Hammond

This is a universal replacement type - it will replace ANY of the 3 audio transformers used (1st audio driver, second audio - phase splitter stage or output transformer), by correctly connecting the 5 lugs. A pin out and connection diagram is included

More+
Features Model
  • Primary: 4,000 turns, #41 wire (lugs 4 & 2)
  • Secondary: 12,000 turns C.T., #41 wire (lugs 5 & 1, lug 3 is C.T. connection)
  • Termination: Solder lugs on a 1 3/4" x 1" terminal board with 4 - 5" connecting leads
  • Size: 1 7/8" long x 1 11/16" wide x 1 3/8" deep
  • Lamination Core Size: 5/8" x 1/2"
  • Weight: 7 oz.
  • Mounting: uses existing case
Mfr. Part No. Description
118944 Lamination Core Size, 0.62
