Honeywell 3-way (A-B-AB) 2in Flange Butterfly Valve VFF3FW1Y2E-M
Honeywell 3-way (A-B-AB) 2in Flange Butterfly Valve VFF3FW1Y2E-M
share
Manufacturer:
Honeywell
Assembly - Length: 11 in.; Height: 15-5/16 in.; Width: 6-13/16 in.; Neck: 5-1/2 in.; Radius; 2-1/4 in.
Dimensions (mm):
Assembly - Length: 279 mm; Height: 389 mm; Width: 173 mm; Neck: 140 mm; Radius; 58 mm
Weight (lb): 40.7 lb
Weight (kg): 18.5 kg
Mounting: ANSI Flanged
More+
Features
Model
Approvals, Underwriters Laboratories Inc.C / US UL873, Plenum Rated
Shipping and Storage Temperature Range (F): -40 F to 250 F
Shipping and Storage Temperature Range (C): -40 C to 121 C
Approvals, CE: Compliant
Enclosure: NEMA 2 housing
Ambient Temperature Range (F): Actuator - 5 F to 140 F
Ambient Temperature Range (C): Actuator - 20 C to 60 C
Connection Type: Lugged
Body Pattern: 3 way (A-B-AB porting)
Pipe Size (inch): 2 in.
Pipe Size (DN): DN50
Maximum Differential Pressure Ratings (Close-off) (psi): 175 psi
Maximum Differential Pressure Ratings (Close-off) (kPa): 1206 kPa
Capacity (Cv): at 60 degrees stroke - 61 Cv; at 90 degrees stroke - 144 Cv
Capacity (Kv): at 60 degrees stroke - 53 kvs; at 90 degrees stroke - 125 kvs
Valve Action: Normally Closeda
