IDEC Micro3C/Micro3 PLC
Manufacturer: IDEC

The Micro3 and Micro3C can be programmed from a PC using WindLDR ladder programming software. A computer link cable is required to connect the PC’s RS232 serial port with the Micro’s programming port.

A network of Micro3s can be set up for programming and monitoring with WindLDR. The network can also be used for supervisory control and data acquisition (SCADA). Up to 32 Micro3s can be networks with a PC as the master. Each Micro3 should be programmed with a specific device number in FUN9. FUN9 can be set with a program loader or with a PC in 1:1 mode running WindLDR.

More+
Features Model
  • All the features of the Micro3
  • Talks both ASCII and binary
  • Equipped with two serial ports, RS232 and RS485
  • Capable of connecting to dial-up modem, serial printer, and bar code reader
  • Up to 500 data registers
  • Handles a wide range of analog input signals
  • Comes with an easy reset button
  • Available in 2 sizes: 16- and 24-I/O with relay output
  • Built-in communications and networking
  • Input/output analog capability
  • User program password protection
  • Catch input, pulse output
  • Real-time clock and calendar available
  • Built-in power supply for sensors
  • Arithmetic, comparison, and Boolean computation
  • High-speed: 400ì/100 steps, 10kHz
Mfr. Part No. Description
FC2A-CA16A1 16 I/O: 9 inputs and 7 outputs
