Jensen DB-2PX-2 Channel Direct Box
Manufacturer: Jensen

The IsoMax is a stereo direct box designed to drive unbalanced instrument signals distances to 100 meters (300') or more without high frequency loss or introducing noise into the signal path.

The design begins with a flanged steel enclosure for easy mounting in a rack or under a desk. This comes standard with 1/4" inputs and XLR outs along with a removable screw-down barrier strip for installers. Inside, two high-performance Jensen JT-DB-EPC transformers provide galvanic isolation as they passively lower the impedance and perform the balancing. A high 140 Ohm input impedance reduces loading, enabling low-output instruments such as a vintage Fender bass to be connected without losing tone. As hi-Z instruments are particularly sensitive to noise, internal Faraday shielding protects against pollution from RF. An external MuMETAL can further protects the sensitive internal workings to ensure a quiet interference-free performance even when surrounded by magnetic fields from amplifiers, power supplies and stage light dimmers.

With over +22 dB of signal handling capacity, the gracefully handles extreme signals such as those produced by digital pianos while producing a warm Bessel response that is often referred to as `vintage' sounding. These features combine to make the the ideal choice for studio or live use

More+
Features Applications Model
  • Converts unbalanced instrument signals to balanced
  • Eliminates hum and buzz caused by ground loops
  • Ruler flat frequency response from 10 Hz to 100 kHz
  • Plug and play easy to use, no power required
  • Passive Direct box with PA: Connect the hi-Z output from your keyboard to the and it will lower the impedance and balance the signal for long cable runs. It also eliminates hum and buzz caused by ground loops.
  • Laptop DI to PA system: Send the stereo output from your laptop, CD player or DJ mixer to the and it will deliver a balanced mic level output to feed a mic splitter or the mic input of your mixing console without noise or distortion.
  • in the studio: The high input impedance, exceptional signal handling and broad frequency response make the a great choice for interfacing electric bass or acoustic guitar to the PA or recording system.
Mfr. Part No. Description
DB-2PX-2 Ruler flat frequency response, from 10 Hz to 100 kHz
