The Iso-Max is a single channel line input isolator designed to eliminate noise in professional balanced audio systems by isolating the input of the connected device.
The design begins with 35 mm DIN rail molded in gray UL94-VO flame retardant Noryl format that snaps into place for easy installation in NEMA enclosures via removable screw-down wire terminal. Plug and play easy to use, this passive interface does not require any power to work. Inside is a Jensen high performance transformer that is able to withstand signal levels to +19 dB @ 20 Hz without discernible distortion. This provides galvanic isolation between the input and output to eliminate hum and buzz caused by ground loops, rejecting noise by as much as 124 dB. To further optimize the performance, a choice of connection point options enable the user to determine the most appropriate grounding scheme to suit the installation.
Mfr. Part No. | Description |
DIN-LI | Ruler flat frequency response, from 5 Hz to 40 kHz |
