Koyo DL205 PLC

share
Koyo DL205 PLC
Manufacturer: Koyo

Five kinds of CPU are available.- Module addition: Up to 8 slot- Maximum I/O points: 8,192 points- Program memory: 2 K to 15.8 K/Data memory: 2.4 K to 30.4 K- Communication port: 2 ports(1 port only for the D2-230)- PID control: Up to 16 build-in loops (D2-260/265)

More+
Features Model
  • For the DL205, ve kinds of CPU that have a wide range of power suppliesand functions at minimized cost are available. For example, the D2-260has a total memory of 30.4K (program memory is 15.8K) installed and cansupport input/output for up to 16,384 points. Moreover, the D2-260 has twobuilt-in communication ports and can be connected to devices such as HMI,serial networks, remote I/O, and ASCII communications. With 260 kinds ofinstructions, it demonstrates a performance equal to a large, strong controlsystem.
  • The base come sin four sizes, and supports 12/24 V DC and 100/200 V ACas the power source.
  • Moreover, therefore more than 60 models of strong input/output modulesand communication modules.
  • Local input/output for all locations
  • If the I/O is installed near the user side device, wiring cost can be reduced.Up to four units can be connected in a range of up to 30 m (overall length)from the local side base unit.
  • Evolving medium-sized PLC
  • The DL 205 series has an enhanced lineup of CPUs with the addition of theD2-265 that has improved functions.
  • Since the expansion of the I/O base is possible, it has better performancespecs than a medium-sized PLC.
  • Abundant lineup of I/O
  • Since numerous I/O modules are available, the DL 205 series can be usedfor various applications.
  • With enhanced communications and networking capabilities, it can be usedfor various networks from Ethernet to remote I/O.
  • Five kinds of CPU in accordance with the scale of system
  • The DL205 series offers five kinds of CPU. You can select the best CPUaccording to the scale of system.
  • Free customization
  • The DL205 series is used by attaching modules to the dedicated bases.2-slot, 3-slot, 5-slot, and 8-slot dedicated bases are available. You can freelyselect a dedicated base according to the scale of system.
  • Expandability
  • The DL205 series can expand I/O up to 1,536 points (when the DL265 CPUis used). Moreover, modules for analog control and communication (Ethernet/DeviceNet) with the host equipment are available, thus providing enhancedexpansion of your system.
  • PID control
  • Each CPU of the DL250-1, DL260 and DL265 has 4- and 16-channel PIDloop functions. you can easily perform PID control by opening the PID controlmenu and setting the designated register using DirectSoft.
  • Easy maintenance
  • The DL205 series adopts a stackable con guration that facilitates moduleconnection and disconnection. If a failure occurs in a module, you can easilyrestore the system by simply replacing the relevant module.
  • Large memory capacity
  • Among the DL205 series, the D2-265 CPU is equipped with a large-capacitymemory of 50.9 kw.
Mfr. Part No. Description
D2-230 Function, Memory 2.4 KMaximum input/output 256 points
