Moog Programmable Multi-Axis Servo Drive (MSD)

share
Moog Programmable Multi-Axis Servo Drive (MSD)
Manufacturer: Moog

A whole new level of machine performance, precision and processing acceleration.

Higher performance machines can mean a real advantage in productivity and profitability for different markets.

The Moog Programmable Multi-Axis Servo Drive System (MSD) answers the call for a new generation of servo drives that provides the highest levels of dynamic response, smooth performance and application versatility.

More+
Features Model
  • Servo drives from 2 to 450 A with the option of either the classic AC Mains connection or a DC feed with a central feeder unit
  • Compact size. Suitable for 300 mm switch cabinet depth, extremely small housing width, for the best possible switch cabinet usage
  • The Single-Axis Compact Version in sizes C2 to C5 includes modular servo drives in a compact format increasing the offering of lower power requirements for single-axis-systems
  • Extendable functionality via flexible MSD design
  • Tailored software packages with Motion Control functionality for every application
  • Support for simultaneous feedback from 3 feedback devices ensures precise positioning capability extending from resolver to Sin/Cos single-turn and multi-turn encoders
  • High-speed communication via fieldbus connection to a wide range of control systems (including EtherCAT, CANopen, PROFIBUS, SERCOS among others)
  • Built in PLC according to IEC/EN 61131 provides functions adapted to the application with direct access to the servo drive peripherals, single and multiaxis operating units
  • Built in functional safety according to IEC/EN 61508, IEC/EN 62061, EN ISO 13849-1, IEC/EN 61800-5-2, personnel safety directly into the servo drive
Mfr. Part No. Description
G391-001-002 Fieldbus option PROFIBUS-DP
G391-001-001 Fieldbus option None
G391-001-003 Fieldbus option EtherCAT
G394-030 Rated current [A] 3.0
G394-059 Rated current [A] 5.9
G394-080 Rated current [A] 8.0
G394-020 Rated current [A] 2.0
G394-035 Rated current [A] 3.0
G394-065 Rated current [A] 6.5
G394-120 Rated current [A] 12.0
G394-160 Rated current [A] 16.0
G392-004 Rated current [A] 4.0
G392-006 Rated current [A] 6.0
G392-008 Rated current [A] 8.0
G392-012 Rated current [A] 12
G392-016 Rated current [A] 16
G392-020 Rated current [A] 20
G392-024 Rated current [A] 24
G392-032 Rated current [A] 32
G392-045 Rated current [A] 45
