Mueller Lineseal 24 and Larger Valve

share
Mueller Lineseal 24 and Larger Valve
Manufacturer: Mueller

Our 24" and larger valves* feature the patented E-LOK® 360°seating system. The body-mounted elastomeric seat has ridges, which provide multiple sealing lines and permit higher levels of radial compression. As a result, stress in the seat material is reduced, allowing lower seating torques and better sealing action. The seat is mechanically retained in a machined groove by a unique cast epoxy design. Uniform pressure around the entire periphery provides a bubble-tight seal. This design also allows seat adjustment or replacement without removing the valve from the line.

Features Model Document
  • Corrosion-resistant Shafts
  • Chevron V-Type Packing
  • Self-lubricating Bearings
  • Elastomeric Seat
  • Flow-through Disc
  • Heavy Duty Body
  • Preset Thrust Bearing Assembly
  • Strong Shaft Connections
Mfr. Part No. Description
