Numatics 503 Series Solenoid Pilot Actuated Valve

share
Numatics 503 Series Solenoid Pilot Actuated Valve
Manufacturer: Numatics

Numatics 503 Valve series provides higher flow and higher reliability in one versatile valve platform. Our 503 Series is available in dual 3-Way and 4-Way solenoid air pilot actuated valves. 503 Series valves are available with manifold or individual base mountings, proprietary or ISO 15407. Numatics 503 series valves are compatible the Numatics G3 Fieldbus Electronics Platform.

More+
Features Model Document
  • Cv 1.0 – 1.4
  • Port Sizes: ¼, 3/8, 8mm, 10mm, Push-In, NPTF & G Tap
  • 5 ported, 2X3-Way, 2 and 3 position, 4 Way, spool & sleeve & rubber seal
  • Operating Pressure Range: 28” HG. Vacuum to 115 PSIG/ Vacuum to 8 Bar
  • Pilot Pressure Range 29 to 115 PSIG / 2 to 8 Bar
  • Temperature Range(Ambient): -14 °F to +115 °F/ - 10°C to 50 °C
  • Numatics 503 Series Solenoid Valve Features:
  • G3 Electronics Compatible
  • Solenoid air pilot actuated
  • Low wattage, 1.7 watt for DC application
  • DC solenoids polarity insensitive with surg suppression
  • Plug together circuit boards eliminate internal wiring
  • Integral recessed gaskets
  • Push-in Fittings to accommodate various tubing sizes
  • Simple conversion from internal to external pilot
  • IP 65 Certified
Mfr. Part No. Description
R503 26 mm Valve, 5 Ported, 2 and 3 position, 4-way
