Omron E6F-A Absolute Rugged Rotary Encoder

Manufacturer: Omron

Rugged housing rotary encoder

The E6F family of dia 60mm rotary encoders features a rugged housing.

This item is an absolute model and comes with an external diameter of 60mm. The resolution is estimated at up to 1,024 (or 10 bit), while the oil-proof protection is of type IP65.

The strong shaft, thrust of 50N and redial of 120N make the item compatible with even more applications and the wider range of resolutions is worth considering.

More+

Features Model Document

Stronger shaft and higher durability (120 N in radial direction and 50 N in thrust direction) than previous E6F Encoders
Drip-proof construction meets IP64F standards
High-resolution models (1024 pulses max. per revolution)
Faster response for high-speed control applications (grey code: 20 kHz)

Mfr. Part No.	Description
E6F-AB3C-C	5 to 12 VDC, NPN open-collector output
E6F-AB3C	5 to 12 VDC, NPN open-collector output
E6F-AB5C-C	12 to 24 VDC, PNP open-collector output
E6F-AB5C	12 to 24 VDC, PNP open-collector output
E6F-AB5B	12 to 24 VDC, PNP open-collector output
