Pepperl Fuchs THI40N Incremental Rotary Encoder
Manufacturer: Pepperl + Fuchs

The THI40 continues the new economical target line of Pepperl+Fuchs. With a small outside diameter of 40 mm, the unit is ideal for use in industrial areas where very little space is available.

The technology of the rotary encoder is adapted to the new requirements of the rotary encoder market. Innovative fast technology with Opto-ASIC forms the central basis of the device. The rotary encoder is available with a pulse count of up to 1024 pulses per revolution.

The rotary encoder is equipped with a metal disk that can accept a high load. It provides the ideal combination of non-sensitivity to temperature and high resolution.

More+
Features Model
  • Compact design
  • Up to 1024 ppr
  • 4.75 V ... 30 V with short-circuit proof push-pull output
  • RS 422 functionality at 5 V operation
  • Loadable metal disk
Mfr. Part No. Description
THI40N-2AAK2R6TN-01024 Hollow shaft Ø5/16 ’’, clamping ring at flange side
THI40N-0SAK2R6TN-01024 Hollow shaft Ø6 mm, clamping ring at flange side
THI40N-0UAK2R6TN-01024 0U Hollow shaft Ø6.35 mm, clamping ring at flange side
THI40N-0CAK2R6TN-01024 0C Hollow shaft Ø8 mm, clamping ring at flange side
THI40N-0XAK2R6TN-01024 0X Hollow shaft Ø3/16 ’’, clamping ring at flange side
THI40N-1SAK2R6TN-01024 1S Hollow shaft Ø6 mm, clamping ring at cover side
THI40N-1UAK2R6TN-01024 1U Hollow shaft Ø6.35 mm, clamping ring at cover side
THI40N-1CAK2R6TN-01024 1C Hollow shaft Ø8 mm, clamping ring at cover side
THI40N-1XAK2R6TN-01024 1X Hollow shaft Ø3/16 ’’, clamping ring at cover side
THI40N-3AAK2R6TN-01024 3A Hollow shaft Ø5/16 ’’, clamping ring at cover side
