Pepperl Fuchs TVI40N Incremental Rotary Encoder
Manufacturer: Pepperl + Fuchs

The TVI40 continues the new economical target line of Pepperl+Fuchs. With a small outside diameter of 40 mm, the unit is ideal for use in industrial areas where very little space is available.

The technology of the rotary encoder is adapted to the new requirements of the rotary encoder market. Innovative fast technology with Opto-ASIC forms the central basis of the device.

The rotary encoder is available with a pulse count of up to 2048 pulses per revolution. The rotary encoder provides the ideal combination of non-sensitivity to temperature and high resolution.

The appearance of this rotary encoder is the tangential cable outlet. This ensures a buckling-free, carefully laying of the connection cable in tangential, radial or axial manner

More+
Features Model
  • Compact design
  • Up to 2048 ppr
  • 4.75 V ... 30 V with short-circuit proof push-pull output
  • RS 422 functionality at 5 V operation
  • Tangential cable outlet
Mfr. Part No. Description
TVI40N-14TK0T6TN-1024 Solid Shaft, 14 Shaft Ø 6 mm x 15 mm
TVI40N-09TK0T6TN-1024 Solid Shaft, 09 Shaft Ø 8 mm x 15 mm
