Schneider Electric Altivar 61 Variable Speed Drive

Manufacturer: Schneider

The Altivar 61 drive is a frequency inverter for 0.75 kW/1 HP to 2400 kW three-phase synchronous and asynchronous motors. It has been designed for common fluid management applications in industrial and commercial buildings and infrastructures.

A specific option, the Active Front End, enables the Altivar 61 to be used in installations where particularly low harmonic levels are required. It also allows the Altivar 61 drive to operate on unstable line supplies.

The Altivar 61 can increase the performance of equipment and reduce operating costs in buildings by optimizing energy consumption whilst improving user comfort.

More+

Features Applications Model Document

UL Type 1/IP20 from 0,75 to 800 kW.
UL Type 12/IP54 from 0,75 to 800 kW.
Speed range: 1:100 in open loop mode.
Overload: 110% ... 120% - 60 s.
Graphic keypad: plain text, navigation button, "Simply Start" menu to start immediately and profit at once from the full performances of Altivar 61. vIntegrated EMC filters class A or B.
Energy saving law, Quadratic motor control law.
Conformity to the international Standards and Certifications: CE, UL, CSA, C-Tick.
Modbus and CANopen integrated.
Communication cards for industry: Ethernet, FIPIO, Modus Plus, DeviceNet, Interbus-S, Unitelway and for building LonWorks, BACnet, METASYS N2 and Apogee FLN.
Inputs/outputs extension cards
Multi pump programmable cards: ATV38 compatibility and new applications.
PowerSuite software: to configure, to set, to save parameters from your applications.
Eco-design.
More than 150 functions available.
Protection of motor and drive:
Safety function: "Power Removal", ATEX.

Range dedicated to pumps and fans applications for industry market and building market: exceptional performances, advanced functionalities.
High performances variable torque applications:
Fan: Safety with forced function (inhibition of the defects, selection of the direction of walk and the reference speed).
Multi pump: With the programmable card multi pump, Altivar 61 bring you flexibility, user-friendliness and adaptability in management of several pumps.
Pumps: Essential functions for your installation protection under load, overload and fluid absence detection.

Mfr. Part No.	Description
ATV61H075M3	ATV61 - 0.75kW 1HP - 200...240V - IP20 - reinforced
ATV61H075M3S337	ATV61 - 0.75kW 1HP - 200...240V - IP20 - reinforced
ATV61H075M3Z	ATV61 - 0.75kW 1HP - 200...240V - IP20
ATV61H075N4	SPEED DRIVE, 1HP,460V,ATV61
ATV61H075N4S337	ATV61 - 0.75kW 1HP - 380...480V - IP20 - reinforced
ATV61H075N4Z	SPEEDDRIVE,1HP,460V,ATV61 LEDKEYPAD
ATV61HC11N4	SPEEDDRIVE,150HP,460V,ATV61
ATV61HC11N4D	SPEED DRIVE 150 HP 460VATV61 NO DC CHOKE
ATV61HC11N4D387	ATV61 - 110kW 150HP - 380...480V - IP20 - wo DC choke
ATV61HC11Y	ATV61 - 110kW / 690V - 125HP / 575V - IP20
ATV61HC11Y387	ATV61 - 110kW / 690V - 125HP / 575V - IP20
ATV61HC13N4	SPEEDDRIVE,200HP,460V,ATV61
ATV61HC13N4D	SPEED DRIVE,200HP,460V,ATV61-NO DC CHOKE
ATV61HC13N4D387	ATV61 - 132kW 200HP - 380...480V - IP20 - wo DC choke
ATV61HC13Y	ATV61 - 132kW / 690V - 150HP / 575V - IP20
ATV61HC13Y387	ATV61 - 132kW / 690V - 150HP / 575V - IP20
ATV61HC16N4	SPEEDDRIVE,250HP,460V,ATV61
ATV61HC16N4D	SPEED DRIVE,250HP,460V,ATV61 NO DC CHOKE
ATV61HC16N4D387	ATV61 - 160kW 250HP - 380...480V - IP20 - wo DC choke
ATV61HC16Y	ATV61 - 160kW / 690V - IP20
