Semikron SKD146/L105 Bridge Rectifier
Semikron SKD146/L105 Bridge Rectifier
share
Manufacturer:
Semikron
Housing: SEMIPONT 6
(LLxBBxHH): 100x45x17
Switches: 6
VRRM / VDRM in V: 1200-1600
ID in A: 140
IFSM / ITSM in A: 1250
More+
Features
Applications
Model
Compact design
Two screws mounting
Heat transfer and isolation through direct copper bonded aluminium oxide ceramic (DCB)
High surge currents
Up to 1600V reverse voltage
UL recognized, file no. E 63 532
IGBT Trench4 inside; max Tj=175°C
CAL4F diode inside, max Tj=175°C
ICM/IFM = 3xIC,nom/IF,nom
Rectifier diode, mx Tj=150°C
DC drives
Controlled filed rectifiers for DC motors
Controlled battery charger
