For a single- or multi-conductor connection, BaseUnits with an appropriate number of terminals are available.
A light BaseUnit opens a new load group. The power supply to the sensors must be fed via this BU. The first BU next to the interface module must always be a light BU.
A dark BaseUnit forwards the power supply of the adjacent light BaseUnit on the left via self-assembling voltage buses. A new infeed is therefore only required on the next light BaseUnit to the right.
All variants that correspond to the BU type of the I/O module can be used as BaseUnits.
Color identification of the terminals
The potentials at the terminals of the BaseUnit are defined by the I/O module. Optionally, the potentials of the terminals can be identified by module-specific color-coded labels to prevent wiring errors. The color-coded label that matches the respective I/O module is defined by the color code CCxx of the I/O module. This color code is also printed on the front of the module. Color-coding labels are not required for modules with color code CC00.
In BaseUnits with 10 internally jumpered AUX terminals, these can also be identified with color-coded labels. For the 10 AUX terminals, color-coded labels are available in red, blue, and yellow/green.
Mfr. Part No. | Description |
6ES7131-6BF00-0AA0 | SIMATIC ET 200SP, DIGITAL INPUT MODULE, DI 8X24VDC BASIC, PACKING UNIT: 1 PIECE, FITS TO BU-TYPE A0, COLOR CODE CC01, MODULE DIAGNOSIS |
