Siemens 6ES7138 1STEP Stepper Module

share
Siemens 6ES7138 1STEP Stepper Module
Manufacturer: Siemens

Parameterization is performed with STEP 7 or a standardized GSD file. In addition, the change of selected parameters is possible from the higher-level control system.

More+
Features Applications Model
  • 1-channel module for ET 200S for controlled positioning of a stepper motor
  • Operating modes: absolute and relative positioning, reference point approach, set reference point and speed mode
  • Connection of power units with pulse/direction interface by means of 5 V differential signals up to 510 kHz
  • External stop with/without ramp via digital input
  • Status display and error indication via LEDs:
  • Errors during positioning and statuses of the digital inputs are indicated by means of LEDs and displayed at the interface to the master
  • Isochronous mode

The 1STEP stepper module enables simple positioning tasks with stepper motor axes.

Mfr. Part No. Description
6ES7138-4DC01-0AB0 ET200S, EL-MOD., 1 STEP 5V/204KHZ
