Siemens CPU1515F-2PN CPU Unit

Manufacturer: Siemens

SIMATIC Memory Card required for operation of the CPU

More+

Features Applications Model

The CPU for applications with medium to high requirements for program/data storage in the S7-1500 controller product range
Can be used for failsafe functions up to SIL 3 according to IEC 61508 and up to PLe according to ISO 13849.
Medium to high processing speed for binary and floating-point arithmetic
Used as central controller in production lines with central and distributed I/O
Supports PROFIsafe in centralized and distributed configurations
PROFINET IO IRT interface with 2-port switch
Additional PROFINET interface with separate IP address
PROFINET IO Controller for operating distributed I/O on PROFINET
PROFINET I-Device for connecting the CPU as an intelligent PROFINET device under a SIMATIC or non-Siemens PROFINET I/O controller
Isochronous mode
Integrated Motion Control functionalities for controlling speed-controlled and positioning axes, support for external encoders
Integrated web server with the option of creating user-defined web pages

The CPU 1515F-2 PN is the CPU with a medium program and data memory for standard and fail-safe applications that also contain distributed automation structures alongside central I/O. It can be used as a PROFINET IO controller or as distributed intelligence (PROFINET I-Device). The integrated PROFINET IO IRT interface is designed as a 2-port switch so that a linear topology can be set up in the system. The additional integrated PROFINET interface with separate IP address can be used, for example, for network separation. In addition, the CPU offers comprehensive control functionalities as well as the ability to connect drives via standardized PLC-open blocks.

Mfr. Part No.	Description
6ES7515-2FM01-0AB0	CPU 1515F-2 PN, 750KB PROG.,3MB DATA

Siemens CPU1515F-2PN CPU Unit
