Siemens CPU1515SPPC CPU Unit

share
Siemens CPU1515SPPC CPU Unit
Manufacturer: Siemens

The CPU 1515SP PC is snapped directly onto the standard mounting rail like other ET 200SP CPUs. ET 200SP I/O modules can be plugged in directly and centrally, and they communicate via the integrated backplane bus. PN IO and S7 communication can be established and distributed I/Os can be connected via the PROFINET adapter of the ET 200SP system. This way, the system can be integrated into existing automation environments with little effort.

The PROFIBUS CM DP module adds PROFIBUS communication to the CPU 1515SP PC.

More+
Features Applications Model
  • Turnkey all-in-one solution with pre-installed SIMATIC S7-1500 software controller and optionally pre-installed WinCC Runtime Advanced V13 SP1
  • Central expansion via ET 200SP modules (station width up to 1 m or up to 64 modules)
  • SIMATIC Hypervisor: for separating Windows systems from control functions
  • Dual-core processor for optimal use of the hypervisor
  • Swappable flash memory (CFast card) for operating system, runtime and project data
  • Integrated DVI-I graphics connection; 3x USB 2.0 connection
  • 2 PROFINET interfaces: X1 via PN-IO bus adapter (RJ45 or FC) with 2 ports; X2: GB-Ethernet interface (RJ45)
  • PROFINET IRT
  • Open Ethernet communication (TCP/IP, UDP, Iso-on-TCP)
  • Web server functionality for information, status, diagnostics and user-defined webpages
  • PROFIBUS DP communication optionally via CM DP module as DP master
  • Configuration control (option handling)
  • Improved know-how and copy protection; Security Integrated
  • Integrated system diagnostics
  • Integrated Motion Control functionalities for controlling speed-controlled and positioning axes with support for external encoders.
  • Trace function
  • Especially suitable for high data volumes and user-specific, open applications
  • Integration of control functions and applications implemented in C/C++ (using SIMATIC ODK-1500S Open Development Kit)

The ET 200SP Open Controller CPU 1515SP PC is a rugged, compact control system that combines the functionality of an ET 200SP controller with a PC-based platform. The CPU offers the entire value added of the ET 200SP system, the S7-1500 controller family and the TIA world combined. The controller can be used to control special and series machines, or to control plants in a distributed configuration. The controller is especially suitable for machines with high data volumes, e.g. for quality assurance with camera inspection and image transmission, or printer connection. The CPU 1515SP PC shows its strengths especially when special automation functions have to be integrated using the programming languages C or C++, when a close connection of Windows software to the software controller is required, or if large volumes of data have to be stored.

Mfr. Part No. Description
6ES7677-2AA31-0EB0 SIMATIC ET 200SP OPEN CONTROLLER, CPU 1515SP PC, 2 GB RAM, 8 GB CFAST W. WINDOWS EMBEDDED STANDARD 7 E 32BIT PREINSTALL., W. S7-1500 SOFTWARE CONTROLLER CPU 1505S V1.8 PREINSTALLED, INTERFACES: 1X SLOT CFAST, 1X SLOT SD/MMC, 1X PLUG F. ET 200SP BUS- ADAPTOR PROFINET, 1X 10/100/1000 MBIT/S ETHERNET, 3 X USB, 1 X DVI-I GRAPHIC INTERFACE, DOCUMENTATION ON DVD, RESTORE DVD
