Siemens CPU1517F-3PN/DP CPU Unit

Manufacturer: Siemens

SIMATIC Memory Card required for operation of the CPU

More+

Features Applications Model

The CPU with a very large program and data memory in the S7-1500 controller product range for failsafe applications with high requirements regarding program scope and networking.
Can be used for failsafe functions up to SIL 3 according to IEC 61508 and up to PLe according to ISO 13849.
High processing speed for binary and floating-point arithmetic
For cross-industry automation tasks in series machine, special machine and plant construction
Used as central controller in production lines with central and distributed I/O
Supports PROFIsafe in centralized and distributed configurations
PROFINET IO IRT interface with 2-port switch
Additional PROFINET interface with separate IP address
PROFINET IO controller for operating distributed I/O on PROFINET.
PROFINET I-Device for connecting the CPU as an intelligent PROFINET device under a SIMATIC or non-Siemens PROFINET IO controller.
PROFIBUS DP master interface
Isochronous mode on PROFIBUS and PROFINET
Integrated Motion Control functionalities for controlling speed-controlled and positioning axes, support for external encoders, positionally precise gearing between axes
Integrated web server with the option of creating user-defined web pages

The CPU 1517F-3 PN/DP is the CPU with a very large program and data memory for demanding standard and fail-safe applications that also contain distributed automation structures alongside central I/O.
It can be used as a PROFINET IO controller or as distributed intelligence (PROFINET I-Device). The integrated PROFINET IO IRT interface is designed as a 2-port switch so that a linear topology can be set up in the system.
The additional integrated PROFINET interface with separate IP address can be used, for example, for network separation.
Distributed I/O can be connected via PROFIBUS via the integrated PROFIBUS interface.
In addition, the CPU offers comprehensive control functionalities as well as the ability to connect drives via standardized PLC-open blocks.

Mfr. Part No.	Description
6ES7517-3FP00-0AB0	CPU 1517F-3 PN/DP, 3MB PROG., 8MB DATA
