Siemens DT Distribution Dry Type Transformer
Manufacturer: Siemens

For industrial and commercial applications with SCR-controlled adjustable speed motor drives, and AC adjustable frequency or DC drives.

Designed for use with motor drives, the drive isolation transformer must isolate the motor from the line and handle the added loads of the drivecreated harmonics.

Drive isolation transformers are engineered for both AC adjustable frequency and DC motor drives.

They are specifically designed to accommodate the electrical and mechanical stresses, regenerative current reversals and frequent short circuits, inherent in severe drive duty

cycles.

More+
Features Model
  • Actual taps may vary based on volts/turn ratio.
  • For outdoor application. Ventilated transformers requiring drip shields are UL listed for outdoor use. No charge when requested at time of initial project order.
  • Items marked floor and wall can be wall mounted with optional wall bracket identified with “W” suffix on catalog number.
  • Refer selection and application guide for additional information on horsepower, Ampere, kVA ratings and applications. Standard taps varies with design volts/turn ratio.
Mfr. Part No. Description
DT007 Motor kVA, 7.5
DT011 Motor kVA, 11
DT014 Motor kVA, 14
DT020 Motor kVA, 20
DT027 Motor kVA, 27
DT034 Motor kVA, 34
DT040 Motor kVA, 40
DT051 Motor kVA, 51
DT063 Motor kVA, 63
DT075 Motor kVA, 75
DT093 Motor kVA, 93
DT118 Motor kVA, 118
DT145 Motor kVA, 145
DT175 Motor kVA, 150
DT220 Motor kVA, 220
DT275 Motor kVA, 250
DT330 Motor kVA, 330
DT440 Motor kVA, 440
DT550 Motor kVA, 550
DT660 Motor kVA, 660
