Siemens F Terminal Module
Manufacturer: Siemens

Terminal modules are purely mechanical components for configuring the ET 200S. They accommodate the electronic modules and motor starter. The modules are automatically coded.

In the terminal modules, integral, self-configuring voltage buses, communications-capable motor starter and its self-configuring 40 A power bus considerably reduce wiring and control cabinet space requirements. The self-assembling shielding of the backplane bus increases data security.

Rugged construction and molded connections support use in a harsh industrial environment (e.g. vibration resistance up to 5 g).

More+
Features Applications Model
  • Mechanical modules as receptacles for the electronic modules
  • For setting up permanent wiring through self-configuring voltage buses
  • Keyed connection technology to ensure an enhanced vibration resistance of up to 5 g
  • Different versions to accommodate power modules and electronic modules
  • Replaceable terminal box (even within the station network)
  • Automatic coding of the electronic modules
  • Self-shielding of the backplane bus for high data security
  • Color coding facility for the terminals and for identifying the slot numbers
  • Alternatively available with screw-type or spring-loaded terminals
  • For up to 60 % faster process wiring also with FastConnect connection method (av. soon)
  • To supply load/encoder voltage on two self-configuring potential buses. A third potential bus (AUX1, max. 230 V) can be used user-specifically, e.g. for continuous supply of light barriers or protective conductors. Power modules are plugged onto TP-M modules for the purpose of voltage monitoring and fusing. Power modules are plugged onto TP-M modules for the purpose of voltage monitoring and fusing. TM-P modules can be used as often as required at any location in the ET 200S. This means that the size of a voltage group can be determined individually. The first module behind the IM151 is always a TM-P with a connected power module
  • Terminal modules for electronic modules (TM-E); TM-E modules accept electronic modules (inputs/outputs, technology modules). The unused signal lines of exclusive OR sensors can also be connected Dedicated double-width terminal modules accept safety-related PROFIsafe electronic modules (F-DI, F-DO and PM E-F).
Mfr. Part No. Description
6ES7193-4CC20-0AA0 SIMATIC DP, TERMINAL MODULE TM-P15S23-A1 FOR ET 200S FOR POWER MODULES 15MM WIDE, SCREW-TYPE TERMINALS 2X3 TERMINAL CONNECTIONS WITH TERMINAL LEAD TO AUX1 AUX1 IN LINE
