Siemens SCALANCEW774RJ45 Module

Manufacturer: Siemens

Access points in SIMATIC design suitable for applications where the device is to be mounted in the control cabinet

More+

Features Model

Low-profile, compact aluminum enclosure, shock and vibration-proof for high mechanical requirements
Implementation of simple and cost-effective wireless machine networking
Support of the 2.4 and 5 GHz frequency band
IP30 protection
For use at ambient temperatures from -20 °C to +60 °C
2 x R-SMA sockets for the connection of direct mountable and remote antennas
Antenna placement optimized for the 2x2 MIMO technology; the antennas do not interfere with each other when they are mounted directly on the device
2 x RJ45 connector for 10/100 Mbit/s, of which one connector has Power-over-Ethernet compliant with IEEE 802.3at
2 x 24 V DC connection for redundant energy supply
1 x PLUG compartment for KEY-PLUG/C-PLUG
Function LEDs for optical signaling of faults/errors and operating statuses
Mounting: Wall, S7-1500 mounting rail, S7-300 mounting rail, or on 35 mm standard mounting rail
SIMATIC design matches existing components in the control cabinet (e.g. S7-1500, …)

Mfr. Part No.	Description
6GK5774-1FX00-0AA0	1 RADIO, 2 R-SMA ANT.
