Siemens SIWAREXWP321 Module

share
Siemens SIWAREXWP321 Module
Manufacturer: Siemens

SIWAREX WP321 is a versatile and flexible weighing module for the seamless integration of a static scale into the SIMATIC automation environment.

The electronic weighing system is integrated in the SIMATIC ET 200SP series and uses all the features of a modern automation system, such as integrated communication, operator control and monitoring, the diagnostic system and configuration tools in the TIA Portal, SIMATIC Step 7 and WinCC flexible.

More+
Features Applications Model
  • Uniform modular design and integrated communication in SIMATIC ET200SP
  • Parameterization of the scales via the control panel, CPU or PC
  • Flexible configuration options in SIMATIC TIA Portal and SIMATIC STEP 7
  • Measuring of weights and forces with a resolution of up to +/- 2 million parts
  • 100 Hz/120 Hz measurement rate (efficient 50/60 Hz interference frequency suppression)
  • Internal scale monitoring of freely definable limit values
  • Easy commissioning using the "SIWATOOL" software
  • Automatic calibration is possible without the need for calibration weights
  • Modules can be replaced without recalibrating the scale
  • Direct use in ATEX Zone 2 possible
  • Wide range of status and diagnostic information
  • "Ready-for-use" sample program
  • Non-automatic scales, e.g. platform scales
  • Fill-level monitoring of silos and hoppers
  • Measuring of crane and cable loads
  • Force measurements
  • Monitoring of belt tensions
  • Setup of scales in hazardous areas
Mfr. Part No. Description
7MH4138-6AA00-0BA0 SIWAREX WP321 WEIGHING ELECTRONIC (1 CHANNEL) FOR STRAIN GAUGE LOAD CELLS / FULL BRIDGES (1-4 MV/V) FOR SIMATIC ET200SP, FITS TO BU-TYPE A0, RS485- INTERFACE FOR CONNECTION OF SIWATOOL OR A REMOTE DISPLAY
