Siemens SM1226 Fail-safe Digital Input Module

Manufacturer: Siemens

Digital inputs as supplement to the integral I/O of the CPUs

Integrated into the overall automation for the implementation of safety-related requirements

With integrated safety functions

Communication with fail-safe CPUs via PROFIsafe mechanisms

For flexible adaptation of the controller to the corresponding task

For subsequent expansion of the system with additional inputs

Operable exclusively in the central system

More+

Features Applications Model

16 inputs (SIL 2/category 3/PL d), 8 inputs (SIL 3/category 3 or category 4/PL e) or a mixture
Rated input voltage 24 V DC
Suitable for switches and 3/4-wire proximity switches (BERO)
Two short-circuit proof sensor supplies, each one for eight inputs; external sensor supply possible
Module fault indicator (DIAG; green and red LED)
Status indicator for each input (green LED)
Fault indicator for each input (red LED)
Plain text identification of module type and function class:
2D matrix code (article and serial number)
Color coding of the module type DI: White
Hardware and firmware version
Complete article No.

The fail-safe modules of the SIMATIC S7-1200 permit the implementation of safety-related application requirements integrated into the overall automation. The safety functions required for fail-safe operation are integrated in the modules. Communication with the failsafe SIMATIC S7 CPUs is performed by means of PROFIsafe mechanisms.
The modules can be operated exclusively in the central system.

Mfr. Part No.	Description
6ES7226-6BA32-0XB0	DIGITAL INPUT SM 1226, F-DI 16X 24VDC
