Siemens SM522 Digital Output Module

share
Siemens SM522 Digital Output Module
Manufacturer: Siemens

8, 16 and 32-channel digital output modules

For flexible adaptation of the controller to the corresponding task

For subsequent expansion of the system with additional outputs

35 mm wide modules with parameters and diagnostic functions

25 mm wide modules for use in tight spaces: particularly economical, without parameters or diagnostic functions

More+
Features Applications Model
  • Mounting on the S7-1500 mounting rail using one single screw
  • 35 mm modules: Standardized 40-pin front connector using screw terminal or push-in technology (cannot be used for 25 mm modules)
  • 25 mm modules: Standardized 40-pin front connector using push-in technology (cannot be used for 35 mm modules)
  • Standardized, harmonized front connector assignment for easier wiring
  • Connectable core cross-sections: 0.25 mm2 to 1.5 mm2 (AWG24 to 16)
  • Integrated potential bridges for flexible creation of potential groups (35 mm modules only)
  • Prewiring position of the front connector
  • Front flap with expandable cable compartment, even if fully wired
  • Unambiguous labeling on front of module:
  • Module type
  • Article No.
  • Hardware and firmware version
  • Channel numbers labeling
  • Cabling diagram
  • Included in the scope of delivery:
  • One labeling strip for manual labeling
  • One U connector
  • Printed front door
  • Front connector (for 25 mm modules only)
  • Digital output modules switch 24 V DC or 230 V AC voltages in the plant and thus transfer internal signals from the controller to the plant. Solenoid valves, DC contactors, and indicator lights can be connected.
  • 35 mm wide output modules have settable parameters and diagnostic functions and can thus be adapted flexibly to the respective process requirements.
  • 25 mm wide output modules do not have settable parameters or diagnostic functions and can therefore be integrated very easily into the engineering. They are recommended for use in locations where only very few input channels are necessary or under conditions of use in which a high number of channels must be implemented in a very limited space.
  • Both module types can be used side by side in one station as required. Uniform features and shared system accessories guarantee easy handling.
