Siemens TM Pulse 2x24V Pulse Output Module
Manufacturer: Siemens

The ET 200SP type B1 BaseUnit is available for connection. The individual signals of the pulse output module are connected to the appropriate terminals.

The type B1 BaseUnit is a dark BaseUnit and forwards the supply voltage of the BaseUnit on the left to its neighbor on the right via self-assembling voltage busbars. The TM Pulse is supplied direct via the infeed terminals of the BaseUnit and is not connected to the neighboring modules.

Due to the high-speed input and output signals, a shielded cable and a low-impedance connection to function ground (DIN rail) are recommended. The BaseUnit of type B1 does NOT offer an integrated connection to the DIN rail. Users must ensure correct shielding themselves.

More+
Features Applications Model
  • 2-channel pulse output module for ET 200SP
  • Operating modes:  Single pulse with defined length
  • Pulse chain with defined number of pulses
  • Pulse width modulation (with flexible ON period, optional current control and dither function)
  • PWM signal for controlling a DC motor
  • On and OFF delay; rising and falling edge can be delayed separately to the microsecond
  • Frequency output with defined output frequency
  • Hardware: 2 24V channels, 2A output current can be switched in parallel to boost performance to 4A of output current
  • Switching frequencies to 10 kHz; at reduced output current to 0.1 A up to 100 kHz
  • Push/pull output driver for especially steep edges at the outputs
  • Polarity change in DC motor operation for direction reversal
  • 1 high-speed 24 V digital input per channel with parameterizable input delay from 4 µs
  • Channel functions: HW enable; Start of signal output with the onboard digital input
  • Parameterizable ON delay; for precise deceleration between the HW enable and the start of output
  • Current measurement in the operating modes pulse-width modulation and pulse chain; enables control of the output current mean value over a period. Temperature influences can thus be balanced to the resistance of the actuator.
  • Cyclic control of the respective main setpoint from the PLC in every operating mode; other values can be modified flexibly from the user program.
  • Supported system functions: Isochronous mode; enables precision-timed connection of the setpoint output to a higher-level controller
  • Firmware update
  • Identification data I&M
  • Packaging industry
  • Food and beverage industry
  • Logistics
  • Presses
  • Automotive engineering
Mfr. Part No. Description
6ES7138-6DB00-0BB1 ET 200SP, TM PULSE 2X24V
