Sola DT Drive Isolation Transformer
Manufacturer: Sola

Drive Isolation Transformers: 7.5–440 kVA, Three Phase Special Voltages and kVA Sizes for Drive ApplicationsFor SCR (Silicon Control Rectifier) variable speed motor drive applications, a transformer is needed to magnetically isolate the incoming line from the motor drive. The transformer must also provide a voltage change to match the required voltage of the SCR Drive. Standard designs are delta primary and wye secondary to match the common power sources required in most three phase rectifier circuits.

SolaHD drive isolation transformers are specifically designed to handle the mechanical stresses, voltage demands and harmonics associated with SCR applications.

More+
Features Model
  • Available from 7.5 thru 440 kVA, 3 Phase, 60 Hz.
  • Isolation minimizes load disturbances caused by the SCR drive.
  • UL Listed/NEMA Type 3R enclosures when used with optional weather shield.
  • Taps on all units for adjustments to incoming source voltage. Full capacity secondary neutral as required by the National Electric Code.
  • Shielding attenuates line to ground noise.
  • 10 year limited warranty
Mfr. Part No. Description
DT651F7.5S Drive Horse Power, 5
DT661F7.5S Drive Horse Power, 5
DT631F7.5S Drive Horse Power, 5
DT651H11S Drive Horse Power, 7.5
DT661H11S Drive Horse Power, 7.5
DT631H11S Drive Horse Power, 7.5
DT651H14S Drive Horse Power, 10
DT661H14S Drive Horse Power, 10
DT631H14S Drive Horse Power, 10
DT651H20S Drive Horse Power, 15
DT661H20S Drive Horse Power, 15
DT631H20S Drive Horse Power, 15
DT651H27S Drive Horse Power, 20
DT661H27S Drive Horse Power, 20
DT631H27S Drive Horse Power, 20
DT651H34S Drive Horse Power, 25
DT661H34S Drive Horse Power, 25
DT631H34S Drive Horse Power, 25
DT651H40S Drive Horse Power, 30
DT661H40S Drive Horse Power, 30
