Square D 260R Rectangular Window Current Transformer
Manufacturer: Schneider

Rating Factor 30 °C Ambient Temp. = 1.33, Rating Factor 55 °C Ambient Temp. = 1.0

Models 260R-252, -302, and -402 Rating Factor 30 °C Ambient Temp. = 1.0, Rating Factor 55 °C Ambient Temp. = 0.75

Ratios are based on one primary turn, with user-applied primary conductor. Refer to page 52 for other ratios using multiple primary turns or secondary turns.

More+
Features Applications Model
  • Features rectangular window for bus conductor applications with minimum clearance requirements.
  • Large, easy-to-read ratios are clearly marked on the case.
  • Secondary terminals are #10-32 brass screws and include flat washers and bronze lockwashers for easy installation.
  • Frequency: 25-400 Hz (Modes 210R and 260R).
  • Insulation: 10 kV BIL full wave (600 volt class).
  • Applicable Standard – ANSI C57.13.
  • UL and CUL recognized per Classification XODW2.
  • Designed for metering applications with minimum clearances.
Mfr. Part No. Description
260R-101 Current Rating q (Amperes), 100:5
260R-151 Current Rating q (Amperes), 150:5
260R-201 Current Rating q (Amperes), 200:5
260R-301 Current Rating q (Amperes), 300:5
260R-401 Current Rating q (Amperes), 400:5
260R-601 Current Rating q (Amperes), 600:5
260R-801 Current Rating q (Amperes), 800:5
260R-122 Current Rating q (Amperes), 1200:5
260R-162 Current Rating q (Amperes), 1600:5
260R-202 Current Rating q (Amperes), 2000:5
260R-252 Current Rating q (Amperes), 2500:5
260R-302 Current Rating q (Amperes), 3000:5
260R-402 Current Rating q (Amperes), 4000:5
