TTV Lug Butterfly Valve DN32-200 PN-16 ANSI 150
TTV Lug Butterfly Valve DN32-200 PN-16 ANSI 150
share
Manufacturer:
TTV
More+
Features
Applications
Model
Document
Renewable seat;
Face to face in acc.with ISO 5752
Actuator mounting flange in acc.with ISO 5211
Materials:
Body in ductile iron GGG-50,rilsan coated;
Disc in stainless steel AISI 316
Stem in stainless steel AISI 303
Connection:
For mounting between flanges according to DIN PN 10/16 and ANSI 150
Working Conditions:
For Pressure up to 10 bar(16 bar up to DN200) and temperatuares from -5 to +90 with peaks up to 120
Water: irrigation, potable water, sea water, water supply, pumping station, industrial water, waste water, fire protection systems, cooling tower
Industry: food, paper mills, chemical, petrochemical, sugar mills, cement industry, petroleum, steel industry
Power generation
Shipbuilding and offshore
Mining
Heating
Air conditioning
Compressed air
Construction
