Vishay EGF1T Surface Mount Ultrafast Plastic Rectifier
Vishay EGF1T Surface Mount Ultrafast Plastic Rectifier
share
Manufacturer:
Vishay
Case: DO-214BA, molded plastic over glass body
Molding compound meets UL 94 V-0 flammability rating
Base P/N-E3 - RoHS-compliant, commercial grade
Base P/NHE3 - RoHS-compliant, AEC-Q101 qualified
Terminals: Matte tin plated leads, solderable per J-STD-002 and JESD 22-B102
E3 suffix meets JESD 201 class 1A whisker test, HE3 suffix meets JESD 201 class 2 whisker test
Polarity: Color band denotes cathode end
More+
Features
Applications
Model
Superectifier structure for high reliability condition
Cavity-free glass-passivated junction
Ideal for automated placement
Ultrafast reverse recovery time
Low switching losses, high efficiency
Avalanche surge energy capability
Meets environmental standard MIL-S-19500
Meets MSL level 1, per J-STD-020, LF maximum peak of 250 °C
AEC-Q101 qualified
For use in high voltage rectification of photoflash application.
