Vishay GP15A/GP15M Glass Passivated Junction Plastic Rectifier

share

Vishay GP15A/GP15M Glass Passivated Junction Plastic Rectifier

Manufacturer: Vishay

Case: DO-204AC, molded epoxy over glass body
Molding compound meets UL 94 V-0 flammability rating
Base P/N-E3 - RoHS-compliant, commercial grade
Base P/NHE3 - RoHS-compliant, AEC-Q101 qualified
Terminals: Matte tin plated leads, solderable per J-STD-002 and JESD 22-B102
E3 suffix meets JESD 201 class 1A whisker test, HE3 suffix meets JESD 201 class 2 whisker test
Polarity: Color band denotes cathode end

More+

Features Applications Model

Superectifier structure for high reliability application
Cavity-free glass-passivated junction
Low forward voltage drop
Low leakage current, IR less than 0.1 μA
High forward surge capability
Solder dip 275 °C max. 10 s, per JESD 22-B106
AEC-Q101 qualified

For use in general purpose rectification of power supplies, inverters, converters and freewheeling diodes for both consumer, and automotive applications.

Mfr. Part No.	Description

Inquiry
