Vishay MBR30HxxCT/MBRB30HxxCT Dual Common Cathode Schottky Rectifier

share
Vishay MBR30HxxCT/MBRB30HxxCT Dual Common Cathode Schottky Rectifier
Manufacturer: Vishay
  • Case: TO-220AB, ITO-220AB, TO-263AB
  • Molding compound meets UL 94 V-0 flammability rating
  • Base P/N-E3 - RoHS-compliant, commercial grade
  • Base P/NHE3 - RoHS-compliant, AEC-Q101 qualified
  • Terminals: Matte tin plated leads, solderable per
  • J-STD-002 and JESD 22-B102
  • E3 suffix meets JESD 201 class 1A whisker test, HE3 suffix
  • meets JESD 201 class 2 whisker test
  • Polarity: As marked
  • Mounting Torque: 10 in-lbs maximum
More+
Features Applications Model
  • Power pack
  • Guardring for overvoltage protection
  • Low power loss, high efficiency
  • Low forward voltage drop
  • Low leakage current
  • High forward surge capability
  • High frequency operation
  • Meets MSL level 1, per J-STD-020, LF maximum peak of 245 °C (for TO-263AB package)
  • Solder bath temperature 275 °C maximum, 10 s, per JESD 22-B106 (for TO-220AB and ITO-220AB package)
  • AEC-Q101 qualified available
  • Automotive ordering code: base P/NHE3

For use in high frequency rectifier of switching mode power supplies, freewheeling diodes, DC/DC converters, and polarity protection application.
