Vishay RS2A/RS2K Fast Switching Surface Mount Rectifier

Manufacturer: Vishay

Case: DO-214AA (SMB)
Molding compound meets UL 94 V-0 flammability rating
Base P/N-E3 - RoHS-compliant, commercial grade
Base P/NHE3 - RoHS-compliant, AEC-Q101 qualified
Base P/NHE3_X - RoHS-compliant, AEC-Q101 qualified
Terminals: Matte tin plated leads, solderable per J-STD-002 and JESD 22-B102
E3 suffix meets JESD 201 class 2 whisker test, HE3 suffix meets JESD 201 class 2 whisker test
Polarity: Color band denotes cathode end

More+

Features Applications Model

Low profile package
Ideal for automated placement
Glass passivated pallet chip junction
Fast switching for high efficiency
High forward surge capability
Meets MSL level 1, per J-STD-020, LF maximum peak of 260 °C
AEC-Q101 qualified available
Automotive ordering code: base P/NHE3

For use in fast switching rectification of power supply, inverters, converters, and freewheeling diodes for consumer, automotive, and telecommunication.

Mfr. Part No.	Description

Vishay RS2A/RS2K Fast Switching Surface Mount Rectifier
