Home Rectifier Vishay SL12/SL13 Low VF Surface Mount Schottky Rectifier

Vishay SL12/SL13 Low VF Surface Mount Schottky Rectifier

share
Vishay SL12/SL13 Low VF Surface Mount Schottky Rectifier
Manufacturer: Vishay
  • Case: DO-214AC (SMA)
  • Molding compound meets UL 94 V-0 flammability rating
  • Base P/N-E3 - RoHS-compliant, commercial grade
  • Base P/NHE3_X - RoHS-compliant and AEC-Q101 qualified (“_X” denotes revision code e.g. A, B)
  • Terminals: Matte tin plated leads, solderable per
  • J-STD-002 and JESD 22-B102
  • E3 suffix meets JESD 201 class 2 whisker test, HE3 suffix
  • meets JESD 201 class 2 whisker test
  • Polarity: Color band denotes the cathode end
Features Applications Model
  • Low profile package
  • Ideal for automated placement
  • Guardring for overvoltage protection
  • Low power losses, high efficiency
  • Very low forward voltage drop
  • High surge capability
  • Meets MSL level 1, per J-STD-020, LF maximum peak of 260 °C
  • AEC-Q101 qualified

For use in low voltage, high frequency inverters, freewheeling, DC/DC converters, and polarity protection applications.

Mfr. Part No. Description
